Use this Garmin quick release plate system to mount and remove the compatible marine component more easily between trips or service intervals.
- Designed for faster installation and removal of the compatible Garmin hardware.
- Useful where a removable mounting arrangement is preferred.
FAQs
Do not use power tools for assembly, as they may damage components and void the warranty. Use hand tools only.
Always wear safety goggles, ear protection, and a dust mask when drilling, cutting, or sanding.
Before drilling or cutting, check the opposite side of the surface to prevent accidental damage to your vessel.
Ensure deck strength for motor weight and force; installation area must be clear for motor movement. Reinforce if needed.
To install the quick release plate, you will need a drill with 11/32 in. (9 mm) bit, 3 and 4 Phillips screwdrivers, 7/16 in. (11 mm) and 1/2 in. (13 mm) sockets, and a torque wrench.
Tighten the nuts to a torque of 14.9 N-m (11 lbf-ft.) when securing the mounting plate to the deck.
Mounting requires countersunk 5/16-18 bolts (M8 x 1.25), preferably stainless steel. Use longer bolts if supplied ones aren’t sufficient.
Use longer 5/16-18 (M8x1.25), countersunk, stainless steel bolts if the provided ones aren’t sufficient for your mounting surface.
Use the template that came with the product. If printing, confirm scaling is 100% and the paper is large enough for the template.
The motor should be mounted on the bow of your boat, with the mount overhanging the gunwale and as close to the center as possible.
