The H5000 Race Display features a large, clear, 5-inch screen, designed for viewing essential data at a glance. A dedicated page key allows quick switching between stored pages which each display 2 data values, updated at rates of up to 10Hz, alongside a unique bar graph providing immediate visual indication of performance targets, countdown timer status and more.
The Race Display is straightforward to install either alongside other H5000 system components, as a display for the highly accurate H5000 CPU data, or as part of a new or existing NMEA 2000® compatible network. With no external metal parts, the durable H5000 Race Display is completely corrosion resistant. It is glass bonded for zero condensation and enhanced contrast.
Key Features
-Bright, 5-inch bonded LCD display: The transflective H5000 Race Display is highly visible both in bright sunlight and at night.
-Visual Target Indicator: The Race Display’s unique bar graph gives you an instant visual on target data, start time and more.
-Low Power: Incredibly low power draw – perfect for offshore racing and blue water cruising
-Tough design – built to last: No external metal parts and completely corrosion resistant, providing you with the peace of mind it can weather the elements – whether the spray of the race or the heat of the sun
-Seamless networking: The H5000 Race Display is NMEA 2000® compatible for ease of integration into your existing network
Product Details
- Extremely High-Contrast Optically Bonded LCD.
- 5″ sunlight viewable, segmented monochrome, wide-screen display.
- Straight-forward user interface.
- System status icons.
- Bargraph option for graphical view of selected data.
- Robust, lightweight ABS construction.
- HV, Race TImer and backlight control for H5000.
Product Specifications
Connectivity
| NMEA 2000 |
1 X NMEA2000 Micro-C Port, 2 LEN |
Display
| Backlight Color |
Red, White |
| Size and Type |
5.0″, Transfective – 7 segment LCD |
Electrical
| Power Consumption, max. |
1.0W |
| Power Consumption, typical |
0.6W |
| Recommended Fuse Rating |
5A |
| Supply Voltage |
12V DC (10-16V DC) |
Environment
| Operating Temperature Range |
-10 to +55ºc (+14 to 131ºf) |
| Waterproof rating |
IPX7 |
MFD
| Compass Safe Distance – Metric, imperial |
300mm (1.0′) |
Physical
| Dimensions (W x H x D) |
172 X 114 X 40mm (6.8 X 4.5 X 1.6″) |
| Mounting Type |
Flush |
| Weight |
0.45 kg (1 lbs) |
Other
| Warranty Period |
2 Years |
| Interface |
keypad |
| Languages |
English, German, Spanish, French, Italian |
