The B&G H5000 Analogue FT/Fathom Depth display shows depth in feet and Fathoms for offshore sailors and racers. A component in the complete B&G H5000 instrument and autopilot system line, which offers a wide range of accurate sensors, processors, and displays that can be combined to create a complete and personalized system for your vessel.
H5000 navigation, instrument and autopilot systems provide accuracy, choice and performance for offshore sailors and racers. Proven over literally millions of ocean miles, H5000 provides a wide range of displays, sensors and processors to provide a complete and personal system.
Product Details
- Front mounted, low profile design.
- ‘Daisy-chain’ option for ease of installation.
- Clear night lighting.
- High integrity mechanical construction including toughened glass display window.
- Compatible with H5000 and H3000 systems.
Product Specifications
Connectivity
| NMEA2000 Pgns |
128267 |
| NMEA 2000 |
2 x NMEA2000 Simnet port, 2 LEN |
Electrical
| Recommended Fuse Rating |
5A |
| Supply Voltage |
12V DC (10-16V DC) |
| Humidity |
Up to 95% RH |
Environment
| Operating Temperature Range |
-10 to +55ºc (+14 to 131ºf) |
| Waterproof rating |
IP67 |
MFD
| Compass Safe Distance – Metric, imperial |
200mm (7.9″) |
Physical
| Dimensions (W x H x D) |
115 X 115 X 68mm (4.5 X 4.5 X 2.7″) |
| Mounting Type |
Flush |
| Weight |
0.5 kg (1.1 lbs) |
