Our V1D1-S00B rocker switch is about as simple as rocker switches come. One input terminal, one output terminal.
This switch has no light. It is latching (meaning it stays on when you press it on).
This genuine Carling Contura switch will fit any of our switch actuators (or covers) – either etched series, or printed switch cover variety.
The biggest advantage of a non-lit switch is that it’s able to run on 12V or 24V marine systems.
V1D1-S00B Rocker Switch Specs:
- Nominal voltage: 12Vdc
- Current Rating: 20A
- Terminals: 2
- Carling P/N: V1D1-S00B
Rocker Switch Wiring Details:
- T2 – input
- T3 – output
Download a printable and savable PDF wiring diagram here
