Specifications:
- Vessel Length: 32′-42′ (10-13 m)
- Voltage: 12 VDC
- Motor Wattage: 1000 Watt
- Max Load: 1100 lb (500 kg)
- Work Load: 275 lb (125 kg)
- Amps Work Load: 100
- Max Line Speed: 48’/min (14.5 m/min)
- Chain Sizes: 5/16 BBB or HT, 3/8 BBB or HT
- Rope Sizes: 1/2, 9/16, 5/8″
- Finish: 316 Stainless Steel
Features:
- Polished stainless steel components
- Rope chain combination gypsy for rope and chain combination or chain only
- Rope Chain Management System (RCMS)
- Quick release integrated swivel chain pipe cover
- Gypsy with low profile clutch top arrangement
- Heavy duty marine grade, dual direction motor in 12V and 24V DC, Hydraulic
- Independent gypsy and capstan operation
- Capstan model features heavy duty knurled finish for increased grip
- Quick fit adaptor
- Stainless steel shaft
- Cone clutch/brake
- Stainless steel mounting bolts
- Shaft seal
- Self lubricating bush
- Clutch release handle
- Made with premium materials
- High-grade design delivers extended lifespan
