Standard Equipment:
- Rope/chain management system
- Two Footswitches
- Watertight Control Box
- Clutch Release Handle
Features:
- Contemporary topworks styling and smooth lines enhance the foredeck
- Our aft facing stainless pressure finger ensures smooth and trouble-free transition from rope to chain during retrieval and deployment
- High ratio gearbox for fast retrieval
- Stainless mainshaft
- Worm drive sealed gearbox
- Radially adjustable gearbox
- Anodized aluminum gearbox housing
- Bronze gears
- Built in chainpipe
- Neoprene deck gasket included
- Clutch handle included
Specifications:
- Motor Wattage 500W
- Version Low Profile
- Finish Chromed Bronze
- Power Rating 850 lbs
- Deck clearance w/standard deck stud Min. 18mm / Max. 30mm (1-1/8″)
- Retrieval Speed @ No Load 45’/min
- Deck clearance w/optional deck stud To 1-3/4″ – Deck Stud Item: LWPDB002
- Amperes @ No Load 40
- Retrieval Speed @ Working Load 52’/min
- Amperes @ Working Load 60
- Approximate Ship Weight (lbs) 22
