Low-friction Bullet blocks lead control lines aft. They are compact and lightweight, with fast trim and release under high or low loads. A range of styles lets these blocks adapt to almost all control line applications. Wire Bullet blocks use roller bearings to carry higher loads and feature hardcoat-anodized PTFE impregnated aluminum sheaves for strength and corrosion resistance.
Product Specifications
Sheave Ø (mm) 29 mm
Sheave Ø (in) 1 1/8 in
Length (mm) 73 mm
Length (in) 2 7/8 in
Weight (g) 35 g
Weight (oz) 1.25 oz
Maximum line Ø (mm) 8 mm
Maximum line Ø (in) 5/16 in
Fasteners (mm) 5 RH mm
Fasteners (in) 10 RH in
Mounting hole spacing (mm) 56 mm
Mounting hole spacing (in) 2 3/16 in
Maximum working load (kg) 227 kg
Maximum working load (lb) 500 lb
Breaking load (kg) 907 kg
Breaking load (lb) 2000 lb
