Find out what’s in the background. Capture what’s in the background. Practice sport fishing at extreme depths with a high-power probe module with the functions you need to increase your chances of success.
Garmin rapidreturn probe
This high-performance technology provides our traditional deep-water probe faster, with a ping rate of 2 to 6 times higher1 than that of our GSD™ 26 probe. This allows captains to make quick and informed decisions based on what is under their boats.
Xchirp technology
Easily distinguish the bait of the fish with the fish bows and the excellent separation of the objectives of our sharpest traditional probe. Get smooth background returns and precise objectives at extreme depths1.
Arfada compensation
When the sea is rough, use the MSC™ 10 satellite compass (sold separately) to greatly reduce the waves and increase the returns of the probe.
Compatibility with transducers
This probe module is compatible with a wide range of Garmin and AIRMAR® transducers (sold separately).
Adaptation
The GSD 28 module is ideal for adaptation to boats with existing bare cable transducers.
Specifications:
Description |
|
| Housing material | Fully sealed aluminum housing, steel back panel, plastic access panel |
| Dimensions | 27,06 cm X 36,66 cm X 10,01 cm (10,7″ X 14,4″ X 4″) |
| Weight | 6,4 kg (14,13 lbs) |
| Classification of water resistance | IPX7 |
| Temperature range | De -15 a 70 °C (de 5 a 158 °F) |
Electrical characteristics |
|
| Electric power | 10-32 V |
| Electricity consumption | 120 W of maximum power |
| Fuse | 15 A |
Characteristics of the probe |
|
| Supported frequencies | Two-channel CHIRP: 25-250 kHz (depends on the transducer) |
| Transmission power | 300 W–3 kW RMS (Depends on the transducer) |
| Maximum depth | 3.048 m (10.000 ft) |
| xCHIRP | Yes |
| RapidReturn™ | Yes |
Connections |
|
| Ports of the Garmin network | 1 (Garmin BlueNet) |
| Probe connections | 2 Stripped wires |
FAQs
Warranty does not apply to damage from unauthorized repairs, unsuitable cables, or operation outside stated guidelines.
Dispose of the device and batteries according to local e-waste regulations. Consult your local waste department for details.
This device has no user-serviceable parts. Repairs should be done only by Garmin authorized service centers.
Do not immerse the device or batteries in water or other liquids, despite its water resistance rating.
Use of nearby terrestrial broadband network devices may cause GNSS signal reception degradation.
Yes. Always supplement electronic depth readings with paper charts and visual indicators for safe marine operation.
Do not leave the device in high-temperature areas such as direct sun on unattended vessels to avoid damage.
