Blue Sea 8378 DC 18 Position Panel – White

DC 18 Position

Description: 3 On/OFF
Voltage: 12v
Amperage: 100A
Installed 15A Single Pole: 15

• All positive, negative and grounding buses installed, fully pre-wired
• Panels with meters include toggle switch for mounting up to 3 battery banks
• All panels with analog meters are owner upgradable to 24 Volts with 8240 or 8243 (18-32V DC meters)
• All circuit label positions are backlit on standard panels – No kit required
• “ON” indicating LEDs installed in all circuit positions

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• AC/DC: DC
• Max Breaker Quantity: 18
• Voltage: 12v
• Box Dimensions: 6″H x 14″W x 22″L WT: 7.65 lbs
• UPC: 632085083786

Quick Guide (pdf)
Owner’s Manual (pdf)

SKU:BLU-8378
